• Dual-sided printing and one-pass waste-free lamination
• 120 cards/hour dual-sided printing and laminating (YMCK ribbon & 1.0 mil laminate both sides)
• Micro-positioning card transport system for enhanced color photos
• Complete system security features & options for printer, ribbons, laminate, cards, and card issuance process
• Covert printing capability – text approx 17 mil high
• Automated card cleaning before printing
• Windows® drivers for 2000 and XP with advanced security features (ID/Log & password protection)
• One year printer warranty
• One year (unlimited passes) printhead warranty

Color Printing

• Color dye sublimation and resin K
• 30 seconds per card (YMCK & dual sided lamination)
• 300 dpi (11.8 dots/mm) print resolution
• No edge-to-edge printing. Must leave 1/16" white border.

Bar Codes

• Bar code and other symbologies available via Windows driver.

Fonts

• True Type or other fonts via Windows™ drivers

Card Specifications

• Types: PVC Composite
• Card width/length: ISO CR-80 – ISO 7810, 2.12” (54mm) x 3.38” (86mm)
• HiCo Magnetic Stripe – ISO 7811
• Contact Smart Card – ISO 7816 Compliant
• Contactless Smart Card – 13.56 MHz
• Card thickness: 27 mil – 33 mil
• Card input hopper capacity: 150 cards

Ribbon Specifications

• YMCK: 600 cards/roll
• YMCKK: 500 cards/roll
• YMCUvK: 500 cards/roll
• Cleaning cartridge: cleans 3,000+ cards

Lamination Specifications

• Linerless & wastefree 1.0 mil laminate, 600 cards/roll
• 2 Laminate cassettes (upper & lower)
• Laminates available
• Clear full size, clear for magnetic stripe cards and clear for smart cards
• Custom laminates available upon request: Holographic images, Special OVD images, UV images

Communications Interface

• USB 1.1 (standard)

Mechanical

Width: 27.5” (699mm) not including exit hopper
Depth: 9.7” (246mm)
Height: 11.5” (292mm)
Weight: 35 lbs (15.9kg)

Electrical

• 110 - 240 Volts AC, 50/60 Hz
• 8 MB image memory standard
• FCC Class A, UL, CUL, & CE approved

Environmental

• Operating Temperature: 50oF to 95oF (10oC to 35oC)
• Operating Humidity: 20% to 80% non-condensing
• Storage Temperature: -4oF to 158oF (-20oC to 70oC)
• Storage Humidity: 5% to 90% non-condensing
• Ventilation: Free air
