Printer Specifications

• Single or Dual-sided Printing
• Color Capability: Full Color, Monochrome
• Print Method: Direct-to-Card Dye Sublimation
• Lamination: None
• Card Feeder: Integrated Card Feeder
• Memory: 20 MB memory (standard)
• Print speed: 102 cards/hr (full color, dual-sided), 130 cards/hr (full color, single-sided)
• Card Feeder/Hopper Capacity
  • Card feeder capacity: 100 cards (30 mil)
  • Card output hopper capacity: 100 cards (30 mil)
  • High capacity card feeder: 220 card (30 mil)

Media Characteristics

Ribbons

• Zebra True Colours iSeries intelligent technology media
• YMCKOK: 170 images/roll
• YMCKO: 200 and 330 images/roll
• 1/2 Panel YMC Full KO: 450 images/roll
• KdO: 500 images/roll
• KrO: 500 images/roll
• Overlay varnishes: clear and hologram: 350 images/roll
• Monochrome ribbon: 1500 and 1000 images/roll

Operating Characteristics

• Operating temperature: 60° F (15° C) to 86° F (30° C)
• Storage temperatures: 23° F (5° C) to 158° F (70° C)
• Operating humidity: 20% to 65% non-condensing
• Storage humidity: 23°F to 158°F (5°C to 70°C)
• Electrical: 100 - 240 Volts AC, 50 - 60 Hz (auto switching)
• Ventilation: Free air
• Agency approvals: FCC Class A, CE, UL, CUL, CCC approved

Physical Characteristics

Width: 26" (660 mm)
Height: 10.1" (256 mm)
Depth: 9.4" (239 mm)
Weight: 20 lbs (9.1 kg)

Related Products

Card Encoding Options

• UHF Gen 2 RFID encoder
• Smart card contact ISO 7816 encoder (30 mil cards only)
• MIFARE/DESFire smart card contactless encoder (30 mil cards only)
• Magnetic encoder, 3 track HiCo/LoCo (30 mil cards only)

Options

• Built-in 10/100 Ethernet
• High capacity card feeder: 220 cards (30 mil cards)
• Extended warranty programs
• Hot swap warranty programs (USA only)

Communication and Interface Capabilities

• USB 1.1 (USB 2.0 compatible) cable included (standard)
• Built-in 10/100 Ethernet (optional)

Bar Codes/Symbologies

Linear Code 39
Other Symbologies via Windows Driver
2-D PDF 417
Code 128 B & C
EAN-8 and EAN-13
Interleaved 2-of-5
UPC-A
Fonts and Graphics True Type fonts via Windows drivers

Card Detail

Card Types

• PVC, PVC Composite, UHF Gen 2 RFID, Adhesive backed
• Magnetic stripe ISO 7811
• Smart card contact and contactless

Card Size: CR80 ISO 7810, 2.12" (54 mm) x 3.38" (86 mm)
Card Thickness: 10 - 60 mil
