• Single or Dual-sided Printing: Single-sided
• Color Capability: Monochrome
• Print Method: Direct-to-Card Dye Sublimation
• Lamination: None
• Card Feeder: Integrated Card Feeder
• Memory: 20 MB memory (standard)
• Print speed: 692 cards/hour (monochrome black)
• Card Feeder/Hopper Capacity
  • Card feeder capacity: 100 cards (30 mil)
  • Card output hopper capacity: 100 cards (30 mil)
  • High capacity card feeder: 220 cards (30 mil) (optional)

Media Characteristics

Ribbons

• Zebra True Colours monochrome ribbon
• Monochrome ribbon: 1500 and 1000 images/roll
• Overlay varnishes (clear and hologram): 350 images/roll

Operating Characteristics

• Operating temperature: 60° F (15° C) to 86° F (30° C)
• Storage temperatures: 23° F (-5° C) to 158° F (70° C)
• Operating humidity: 20% to 65% non condensing
• Storage humidity: 20% to 70% non-condensing
• Electrical: 100 - 240 Volts AC, 50 - 60 Hz (auto switching)
• Ventilation: Free air
• Agency approvals: FCC Class B, CE, UL, CUL approved

Physical Characteristics

Width: 18.2" (462 mm)
Height: 10.1" (256 mm)
Depth: 9.4" (239 mm)
Weight: 15.5 lbs (7 kg)

Related Products

Card Encoding Options

• Smart card contact station (30 mil cards only)
• Contactless encoding
• Magnetic encoder (20-40 mil cards only)

Options

• Built-in 10/100 Ethernet
• High capacity card feeder: 220 cards (30 mil)
• Extended warranty program
• Hot swap warranty program (USA only)

Communication and Interface Capabilities

• USB (USB 2.0 compatiible) cable included (standard)
• Built-in 10/100 Ethernet (optional)

Bar Codes/Symbologies

Linear Other Symbologies via Windows Driver
2-D PDF 417
Code 128 B & C
EAN-8 and EAN-13
Code 39
Interleaved 2-of-5
UPC-A

Fonts and Graphics: True Type fonts via Windows™ drivers.

Card Detail

Card Types

• PVC, PVC Composite, Adhesive backed
• Magnetic stripe - ISO 7811
• Smart card contact and contactless

Card Size: CR-80 - ISO 7810, 2.12" (54 mm) X 3.385" (86 mm)
Card Thickness: 10 - 60 mil
