Q2i

  • Full Colour Screen To Display Pictures, Advertisements And Screen Savers.
  • Verification Through Card Or Password Or Even The Combination Of Two.
  • Handles Up To 10,000 Fingerprints And Over 2lakh Transactions.
  • Shortcut Keys To Be Programmed To Commonly Used Functions.
  • An External Alarm For Emergency Purpose During Unexpected Scenarios.
  • Work Code Allows The Employees To Intimate Their Whereabouts By Selecting The Predefined Templates.
Download Brochure
MODELQ2i
SURFACE FINISHING Acrylonitrile Butadiene Styrene (ABS)
TYPE OF SCANNER Optical
MICROPROCESSOR 800 MHz microprocessor
MEMORY256MB flash memory and 64MB SDRAM
ALGORITHM BioBridge VX 9.0 / VX 10.0
PRODUCT DIMENSION (L X W X H), mm 200 x 56 x 160
STORAGE
Fingerprint templates10000
Card Capacity10000
Transaction200000
ENROLLMENT & VERIFICATION
MethodsFingerprint (1:1, 1:N), Card & Password
Recommended Fingerprint per user ID2
Fingerprint placementAny angle
Verification time (sec)< 1
FAR (%)< 0.0001
FRR (%)< 1
CARD TECHNOLOGY
RFID: 64-bit, 125kHzYes
MIFARE: MFIS50/S70, 13.56MHzMade to order
HID: HID 1325, 26-bit, 125kHzMade to order
COMMUNICATIONS
MethodTCP/IP, RS232, RS485, USB flash disk, (Optional: WiFi, GPRS & 3G)
Baud Rates9600, 19200, 38400, 57600, 115200
Wiegand26-bit input/output
OPERATING ENVIRONMENT
Temperature (°C)0 ~ 45
Humidity (%)20 ~ 80
Power inputDC 12v 3A
TIME ATTENDANCE
SirenBuilt- in (Optional - External)
Work CodesYes
MULTIMEDIA
VoiceYes
Display3.5” 65k color TFT screen
Short messagingYes
ACCESS CONTROL
EM lock driving output DC12V 3A / Relay output
Alarm output NO/NC
Antipassback Yes
VOICE / DISPLAY LANGUAGE (TERMINAL)English (Standard), Arabic, Malay, Indonesian, Chinese (Traditional), Chinese (Simplified), Cantonese, Thai, Spanish, Portuguese (Portugal), Portuguese (Brazil), French, Russian, German, Italian, Turkish, Persian. Other languages are available upon request.
SOFTWAREIngress
